PRO B760M-A WIFI
PRO B760M-A WIFI
PRO B760M-A WIFI
PRO B760M-A WIFI
PRO B760M-A WIFI
PRO B760M-A WIFI
PRO B760M-A WIFI

PRO B760M-A WIFI

PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity. PRO B760M-A WIFI is designed with tons of flexible tools and convenient Wi-Fi solution with DDR4 memory version.


  • Supports Intel® Core™ 14th, 13th and 12th Gen Processors, Intel® Pentium® Gold, Celeron® Processor and Intel Processor 300(T)
  • Supports DDR5 Memory, Dual Channel DDR5 6800+MHz (OC)
  • Enhanced Power Design: 12+1 Duet Rail Power System with P-PAK, 8-pin + 4-pin CPU power connectors, Core Boost, Memory Boost
  • Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK and additional choke thermal pads are built for high performance system and non-stop gaming experience
  • High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material
  • Lightning Fast Game experience: PCIe 4.0 slot, Lightning Gen 4 x4 M.2
  • Intel Turbo USB 3.2 Gen 2: Powered by Intel USB 3.2 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speeds
  • 2.5G LAN with Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
  • AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience

Free Shipping

Free Shipping

On order over $25

Return for Refund

Return for Refund

Within 30 days

1-YEAR Limited Warranty

3-YEARS Limited Warranty

Base-on purchase date

Limited Time Offer
$169.99 $159.99
In Stock

DETAIL SPECIFICATION

OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
Manufacturer Number PRO B760M-A WIFI
Product Condition New
CPU Supports Intel® Core™ 14th, 13th and 12th Gen Processors, Intel® Pentium® Gold, Celeron® Processor and Intel Processor 300(T)
Processor socket LGA1700
Chipset Intel® B760 Chipset
CPU Socket LGA1700
Form Factor M-ATX Form Factor
Memory 4 x DDR5 memory slots, support up to 192GB
Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max overclocking frequency:
  • 1DPC 1R Max speed up to 6800+ MHz
  • 1DPC 2R Max speed up to 6400+ MHz
  • 2DPC 1R Max speed up to 6000+ MHz
  • 2DPC 2R Max speed up to 5600+ MHz

  • Supports Intel® XMP 3.0 OC
    Supports Dual-Controller Dual-Channel mode
    Supports non-ECC, un-buffered memory
    LAN Realtek® RTL8125BG 2.5G LAN
    Wireless LAN Intel® Wi-Fi 6E
    The Wireless module is pre-installed in the M.2 (Key-E) slot
    Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
    Supports 802.11 a/ b/ g/ n/ ac/ ax
    Bluetooth Supports Bluetooth® 5.3, FIPS, FISMA
    Audio Realtek® ALC897 Codec
  • 7.1-Channel High Definition Audio
  • MULTI-GPU -
    STORAGE 2 x M.2 Gen4 x4 64Gbps slot
    4 x SATA 6Gbps ports
    Onboard Graphics 2 x HDMI™
    2 x DisplayPort
    Support HDMI™ 2.1, maximum resolution of 4K 60Hz
    Support DP 1.4, maximum resolution of 4K 60Hz
    RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
    I/O (Rear) Keyboard / Mouse
    DisplayPort
    USB 3.2 Gen 1 5Gbps (Type-A)
    2.5G LAN
    Wi-Fi / Bluetooth
    Audio Connectors
    USB 2.0
    HDMI™
    USB 3.2 Gen 2 10Gbps (Type-A)
    Expansion Slots 2 x PCI-E x16 slot
    1 x PCI-E x1 slot
    PCI_E1 PCIe 4.0 supports up to x16 (From CPU)
    PCI_E2 PCIe 3.0 supports up to x1 (From Chipset)
    PCI_E3 PCIe 4.0 supports up to x4 (From Chipset)
    USB (Front) 4 x USB 3.2 Gen1 Type A
    1 x USB 3.2 Gen1 Type C
    4 x USB 2.0
    USB (Rear) 2 x USB 3.2 Gen1 Type A
    2 x USB 3.2 Gen2 Type A
    2 x USB 2.0
    TYPE-C PORT -
    Internal Connectors 1 x Power Connector(ATX_PWR)
    2 x Power Connector(CPU_PWR)
    1 x CPU Fan
    1 x Pump Fan
    2 x System Fan
    2 x Front Panel (JFP)
    1 x Chassis Intrusion (JCI)
    1 x Front Audio (JAUD)
    1 x Com Port (JCOM)
    2 x Addressable V2 RGB LED connector (JARGB_V2)
    1 x RGB LED connector(JRGB)
    1 x TPM pin header(Support TPM 2.0)
    4 x USB 2.0
    4 x USB 3.2 Gen1 Type A
    1 x USB 3.2 Gen1 Type C
    Dimensions 9.60" x 9.60"
    Manufacturer Warranty 3 Year
